Diamond Squaring Wheels for Ceramic Tile Edge Finishing

BASAIR > Abrasives > Diamond Squaring Wheels for Ceramic Tile Edge Finishing

BASAIR supplies diamond squaring wheels for ceramic and porcelain tile edge finishing. These wheels are used on squaring and chamfering machine lines to correct tile dimensions, improve edge quality and support stable production-line output.

The product range includes dry squaring wheels, wet squaring wheels, metal bond squaring wheels, resin bond squaring wheels and chamfering wheels.

Dry Diamond Squaring Wheels

Dry diamond squaring wheels are used on dry squaring machine lines for ceramic tile edge processing. They are suitable for factories that use dry edge grinding with dust collection instead of water-assisted grinding.

Typical Applications

Dry squaring for ceramic tiles
Dry edge finishing for porcelain tiles
Production-line edge correction
Tile sizing before sorting or packaging
Dry squaring and chamfering machine lines

Key Features

Designed for dry working conditions
Stable edge grinding on continuous lines
Compatible with dry squaring machines
Selected according to tile body, line speed and edge finish
Supports cleaner tile dimension control

Wet Diamond Squaring Wheels

Wet diamond squaring wheels are used when water is part of the tile edge grinding process. Wet squaring can help with cooling, dust control and stable edge finishing during continuous ceramic tile production.

Typical Applications

Wet squaring for ceramic and porcelain tiles
Edge grinding with water cooling
Factory lines with water circulation
Stable edge correction for standard tile formats
Squaring and chamfering before final sorting

Key Features

Suitable for wet grinding conditions
Supports stable edge contact
Helps control heat during grinding
Selected according to tile hardness and production speed
Works with wet squaring and chamfering machine lines

Metal Bond Squaring Wheels

Metal bond squaring wheels are used for stronger cutting and material removal during edge processing. They are commonly selected for earlier squaring positions where the wheel needs to remove more material and maintain shape stability.

Suitable For

Stronger edge grinding
Initial squaring positions
Hard ceramic or porcelain tile bodies
Production lines requiring stable material removal
Applications where wheel shape retention is important

Resin Bond Squaring Wheels

Resin bond squaring wheels are used for finer edge finishing and smoother tile-edge results. They are often selected after metal bond wheels or in positions where the factory needs cleaner edge quality.

Suitable For

Finer edge finishing
Later squaring positions
Cleaner tile edge appearance
Reducing visible edge marks
Production lines that need more controlled finishing

Chamfering Wheels

Chamfering wheels are used to create a controlled bevel on ceramic or porcelain tile edges. This helps reduce sharp edges, improve handling and support a cleaner finished appearance.

Typical Applications

Ceramic tile chamfering
Porcelain tile beveling
Edge preparation before packaging
Chamfering after squaring
Finished edge appearance control

Name / No.	Working Condition	Rim Type	Outer Diameter (mm)	Inner Diameter (mm)	Screw Hole Distance (mm)	Segment Height (mm)	Segment Width (mm)	Segment Outer Diameter (mm)	Segment Inner Diameter (mm)
Diamond Wheel - 01/02	Dry	Toothless	250	80	105/110	10	10	250	230
Diamond Wheel - 01/02	Dry	Toothless	200	80	105/110	10	10	200	180
Diamond Wheel - 01/02	Dry	Toothed	250	80	105/110	20	12	250	226
Resin Bond Wheel - 03/04	Dry	Toothless	240	80	105/110	25	20	240	200
Resin Bond Wheel - 03/04	Dry	Toothless	200	80	105/110	25	15	200	170
Resin Bond Wheel - 03/04	Dry	Toothed	240	80	105/110	35	18	240	204
Diamond Wheel - 01/02	Wet	Toothed	250	140	165	10	14	250	222
Resin Bond Wheel - 03/04	Wet	Toothless	200	140	165	25	17	200	166
Resin Bond Wheel - 03/04	Wet	Toothless	240	140	165	30	17	240	206
